Bently Nevada | Proximeter Extension Cable 21747-045-01

Description

Bently Nevada Proximitor Probe Extension Cable 21747-045-01
Model Suffix Decoded: 045 = 4.5 meters (177 inches) | 01 = Armored. Designed for industrial vibration monitoring, this system combines precision engineering with rugged durability.

Core Specifications

• Scale Factor: 200 mV/mil (7.87 V/mm) ±4%, validated at 10 mil increments with AISI 4140 steel targets.
• Armor Construction: 304 stainless steel braiding for abrasion and chemical resistance.
• Calibration Range: Measures 80 mils (2.0 mm), starting from 10 mils (0.25 mm) proximity.
• Interchangeability Tolerance: ±9.5% system error margin.

Performance Highlights

• Power Efficiency: Operates at 12 mA with -17.5V to -26V DC input.
• Temperature Resilience: Functions in -60°F to +350°F (-51°C to +177°C) with -3% scale factor drift at +150°F (+65°C).
• Frequency Response: 0-10 kHz (±5%), ideal for high-speed machinery diagnostics.
• Corrosion Resistance: Compatible with sulfuric acid (10%), MEK, DMF, and oils.

Physical & Environmental

• Weight: 1.3 lbs (0.59 kg) for easy installation.
• Humidity Tolerance: Up to 95% non-condensing environments.
• Probe Compatibility: Optimized for 8 mm probes.

Technical Support & Bulk Orders: sales@nex-auto.com

Download PDF file here:7200 Proximity Transducer Systems
