330878-90-00 | Bently Nevada – Proximitor Sensor

Description

Bently Nevada 3300 XL 50mm Sensor

Core Advantages

Ultra-long 9m system (29.5ft) for flexible panel/DIN-rail setups. Factory-tuned for AISI 4140 steel. Optional calibration for custom materials.

Performance Highlights

• Brand/Model: Bently Nevada 330878-90-00
• Voltage: -17.5V to -26VDC (12mA max)
• Accuracy: ±0.25% full scale
• Material: A380 aluminum housing

Environmental Ratings

• Operation: -51°C to +100°C (-60°F to +212°F)
• Storage: -51°C to +105°C (-60°F to +221°F)
• Humidity: 0–95% non-condensing

Quick Install Guide

Tool-free SpringLoc terminals support 12–24 AWG wires. Compatible with 3300 XL series probes.

Quality Assurance

• 1-year limited warranty
• 50,000+ hour MTBF rating
• IP54 protection standard

Industrial Use Cases

• Oil pipeline vibration analysis (0–5kHz range)
• Hydroelectric turbine monitoring
• Paper mill roller alignment checks

Download PDF file here:3300 XL 50 mm Proximity Transducer System Datasheet
