Bently Nevada | Proximity Armored Probes | 330102-11-45-50-11-CN

Description

Bently Nevada 3300 XL 8mm Proximity Probe: Heavy-Duty Industrial Sensing

Model Breakdown

Full ID: 330102-11-45-50-11-CN
• Suffix Key: 11=1.1″ Unthreaded | 45=4.5″ Case | 50=5m Cable | 11=FluidLoc Connector
• Special Note: Exclusively pairs with 5m Proximitor® sensors

Core Specifications

• Detection Range: 0.25-2.3mm (10-90 mils)
• Output Signal: -1V to -17V DC linear response
• Optimal Gap: -9V DC (50 mils setting)
• Works in -62°F to +500°F extremes
• Viton® O-ring pressure sealing

Advanced Features

• FluidLoc™ waterproof cable
• ClickLoc connector with safety lock
• 3/8-24 UNF thread (0.563″ max engagement)
• 323g/m stainless steel housing

Global Certifications

• ATEX/IECEx Certified
• Class I Zone 0 & 2 compliance
• Groups A-G explosive atmosphere rating

Package Includes

• 8mm Probe (5m cable)
• FluidLoc Connector Kit
• Installation Manual
• 1-Year Quality Warranty

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
