Bently Nevada 330707-00-30-10-02-00 – Proximity Probe

Description

Manufacturer: Bently Nevada

Product Number: 330707-00-30-10-02-00

Product Type: 3300 XL 11 mm Proximity Probe

Origin: Made in U.S.A (Certificate of Origin available)

Model Breakdown:

• 330707: 5/8-18 UNF thread, no armor
• Unthreaded Length: 00 = 0 in
• Overall Case Length: 30 = 3.0 in
• Total Cable Length: 10 = 1.0 meter (3.3 ft)
• Connector: 02 = Miniature coaxial ClickLoc, standard cable
• Agency Approval: 00 = Not required

Material & Construction:

• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 304 stainless steel (SST)
• Cable: 75 Ω triaxial, FEP insulated (1, 5, or 9 m available)

Electrical Details:

• DC Resistance (1.0 m): 5.9 ± 0.5 ohms
• Connector Torque: Max 0.565 N·m (5 in·lb), finger-tight recommended
• Minimum Bend Radius: 25.4 mm (1.0 in)

Thread & Torque:

• Main Thread: 5/8-18 UNF, Max thread engagement 0.938 in
• Additional Threads: M16x1.5 (24 mm), M14x1.5 (21 mm)
• Torque Limit: Max 45.2 N·m (400 in·lb), Recommended 15.2 N·m (133 in·lb)

Environmental Ratings:

• Operating/Storage Temp: -52°C to +177°C (-62°F to +351°F)
• Seal Warning: May fail below -34°C (30°F)
• Seal Type: Viton O-ring for pressure differential sealing

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
