Bently Nevada – 330707-00-24-90-11-05 – Proximity Probe

Description

Product Overview

The 330707-00-24-90-11-05 is an 11 mm proximity probe by Bently Nevada.
It has a 5/8‑18 UNF thread, a 2.4 in case,
and a 9.0 m FluidLoc cable with protector.

Model Breakdown

• 330707 = 11 mm probe
• 00 = 0 in unthreaded
• 24 = 2.4 in case length
• 90 = 9.0 m cable length
• 11 = ClickLoc connector + protector
• 05 = multiple approvals

Key Specifications

• Tip Material: PPS
• Case Material: AISI 304 SST
• Cable: 75 Ω triaxial FEP
• Weight: 0.17 kg
• Temp Range: -52 °C to +177 °C
• Shelf Life: 1 year

Mechanical & Electrical

• Bend Radius: 25.4 mm
• Thread Depth: UNF 0.94 in; M16×1.5 24 mm; M14×1.5 21 mm
• Probe Torque: Max 45 N·m, Rec 15 N·m
• Connector Torque: Max 0.6 N·m, Rec finger‑tight
• Resistance (9 m): 8.5 ± 1.1 Ω

Performance Highlights

• Insulation: ≥ 1×10⁶ MΩ @100 V
• Capacitance: ~ 30 pF
• Shock Rating: 5000 g, 0.5 ms
• Vibration: 10 g @5–500 Hz
• Response Time: < 0.1 ms

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
