New Proximity Probes – Bently Nevada 330707-00-10-90-11-00

Description

Product Overview

The Bently Nevada 330707-00-10-90-11-00 is a 3300 XL 11 mm Proximity Probe. It uses a 5/8-18 UNF thread and has no armor. The total cable length is 9.0 meters (29.5 ft). This model includes a FluidLoc sealed cable with a ClickLoc miniature coaxial connector.

Main Specifications

Probe Tip Material: PPS

Case Material: Stainless Steel (AISI 304)

Cable Type: 75 Ω triaxial, FEP insulated, FluidLoc sealed

Thread Size: 5/8-18 UNF

Unthreaded Length: 0 in

Case Length: 1.0 in

Total Length: 9.0 m

Connector Type: ClickLoc with protector

Agency Approval: Not required

Electrical and Mechanical

DC Resistance (9 m): 8.5 ± 1.1 Ω

Maximum Thread Engagement: 0.938 in

Case Torque: Max 400 in·lb, Recommended 133 in·lb

Connector Torque: Max 5 in·lb, Finger tight recommended

Minimum Bend Radius: 25.4 mm (1.0 in)

Environmental

Temperature Range: –52 °C to +177 °C (–62 °F to +351 °F)

Humidity: Up to 98% RH, non-condensing

Shock Resistance: 50 g, 11 ms

Vibration Resistance: 10 g, 10–300 Hz

Seal Type: Viton® O-ring (for pressure sealing)

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
