100% Original Brand New Transducer Bently Nevada 190501-12-00-01

Description

Overview

The Bently Nevada 190501-12-00-01 Velomitor CT Velocity Transducer provides exceptional vibration monitoring for critical machinery. Built in USA with a rugged 316L stainless steel case and M8×1 plate stud mounting, it offers precision feedback under extreme conditions.

Model Breakdown

• 190501: Velomitor CT family
• 12: Plate stud 3/8‑24 to M8×1
• 00: Standard MIL‑C‑5015 connector
• 01: CSA/NRTL/C & ATEX/IECEx approvals

Key Specifications

• Sensitivity: 3.94 mV/mm/s ± 5%
• Frequency Response:
  • 3 Hz–900 Hz (± 1 dB)
  • 1.5 Hz–1.0 kHz (± 3 dB)
• Noise Floor: 0.10 µm/s/√Hz at 100 Hz
• Resolution: 0.25 µm/s
• Output Bias Voltage: 10.1 Vdc ± 1 V
• Amplitude Linearity: ± 2% up to 63.5 mm/s pk
• Resonant Frequency: ≥ 9 kHz
• Response Time: < 0.4 ms

Environmental & Mechanical

• Operating Temp: –40 °C to +85 °C
• Storage Temp: –40 °C to +100 °C
• Shock Limit: 5000 g pk
• Humidity: 100% condensing
• Mounting Torque: 4.5 N·m ± 0.6 N·m
• Weight: 297 g
• Dimensions: 33 mm Ø × 82 mm H
• Cable Bend Radius: ≥ 10 mm

Download PDF file here:190501-Datasheet
