2-Wire Vibration Transmitter Bently Nevada 990-10-70-03-CN

Description

990‑10‑70‑03‑CN Vibration Transmitter

Quick Look

Bently Nevada delivers precise vibration data with a simple 4–20 mA output. Designed in the USA for reliable monitoring.

Model Breakdown

‑10:

0–10 mils pp (0–250 μm pp)

‑70:

7.0 m (23 ft) cable

‑03:

DIN clips & screws

‑CN:

Country approvals

Key Specs

Range: 0–10 mils pp
Accuracy: ±1.5% FS
Supply: +12 to +35 Vdc
Loop R: ≤1 000 Ω
Response: 5 Hz–6 000 Hz ±3 dB
Weight: 0.43 kg (0.9 lb)

Installation

Mount on a 35 mm DIN rail with clips and screws. Plug in one 3300 NSv probe (max 3 m cable). Adjust zero and span externally.

Compatibility

Works with non‑contacting 3300 NSv Proximity Probes. Suited for Zone 2/Div 2 areas.

Certifications

CN approvals for local agencies.

Box & Warranty

Includes transmitter, DIN clips, cable, and manual. 1‑year warranty on parts and labor.

Download PDF file here:990 Vibration Transmitter Datasheet
