21504-00-08-05-02 Bently Nevada 8mm Proximity Probe

Description

Model: 21504-00-08-05-02

Part Number: 21504
Manufacturer: Bently Nevada
Condition: New & Original in factory packaging
Warranty: 1 year

Suffix Configuration:
00 = Unthreaded tip: 0 mm
08 = Case length: 80 mm
05 = Cable length: 0.5 m (20 in)
02 = Miniature coaxial male connector

Tip Construction: 8 mm diameter, standard housing, 3/8‑24 thread, no lead armor

Electrical Input:
Voltage: –17.5 V to –26 V
Current Draw: Max 12 mA

Performance Output:
Calibrated Range: 2.0 mm (80 mils)
Sensing Start Distance: 0.25 mm from probe face
Scale Factor: 200 mV/mil (7.87 V/mm), ±4% system-calibrated
Linearity: ±0.02 mm typical, ±0.06 mm with interchangeability
Frequency Response: 0–10 kHz (600,000 cpm), –5% at 10 kHz
