21504-00-40-50-02 Bently Nevada 8mm Proximity Probe

Description

Model: 21504-00-40-50-02

Part Number: 21504
Manufacturer: Bently Nevada
Condition: New & Original in factory packing
Warranty: 12 Months

Suffix Configuration:
00 = Unthreaded Length: 0 mm
40 = Case Length: 4.0 in (101.6 mm)
05 = Total Length: 0.5 m (20 in)
02 = Connector: Miniature male coaxial

Tip Construction:
Diameter: 8 mm
Thread: 3/8-24
Case: Standard
Lead Armor: No

Input:
Power: –17.5V to –26V DC
Max Current: 12 mA

Output:
Range: 80 mils (2.0 mm)
Starts at: 10 mils (0.25 mm)
Scale: 200 mV/mil (7.87 V/mm), ±4%
Linearity: ±0.02 mm (system-calibrated), ±0.06 mm with errors
Frequency: 0–10 kHz (600,000 cpm); -5% at 10 kHz

Temperature Sensitivity:
Change at 65°C: –396 at 1.27 mm gap

Environmental Limits:
Proximitor: –51°C to +100°C
Probe Cable: –34°C to +177°C
Humidity: 95% max, non-condensing
Corrosion Resistance: Air, water, oils, ammonium, sulfuric acid, MEK, DMF

Download PDF file here:7200 Proximity Transducer Systems
