3300 NSv Probe Bently Nevada – 330903-00-03-05-02-00

Description

Bently Nevada 330903-00-03-05-02-00 | 3300 NSv Proximity Probe

Model Breakdown

Model: 330903 – 3300 NSv Probe
Thread Type: M8x1
Unthreaded Length: 00 mm
Overall Case Length: 30 mm
Total Cable Length: 0.5 meter (20 in)
Connector: Miniature coaxial ClickLoc, standard cable
Agency Approval: Not required

Key Technical Specifications

Brand: Bently Nevada
Model: 330903-00-03-05-02-00
Linear Range: 1.5 mm (60 mils)
Recommended Gap: 1.0 mm (40 mils)
Scale Factor: 7.87 V/mm (200 mV/mil) ±12.5%/-20%
DSL (Accuracy): ±0.06 mm (±2.3 mils)
Frequency Response: 0 to 10 kHz (-3 dB max)
Probe DC Resistance: 4.0 ± 0.5 Ω at 0.5 m
Output Signal: Analog voltage
Operating Temperature: -52°C to +177°C (-62°F to +351°F)
Storage Temperature: -52°C to +177°C
Minimum Target Size: 8.9 mm (recommended ≥13 mm)
Probe Pressure Seal: Viton O-ring (not pressure-tested by default)
Cable Type: FEP insulated 75 Ω coaxial
Bend Radius: 25.4 mm (1 in)
Installation Torque: Finger-tight recommended; Max 0.56 N·m (5 in·lb)

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
