330130-085-13-05 | Extension Cable – Bently Nevada

Description

Bently Nevada Extension Cable

Model 330130-085-13-05. Engineered for industrial connectivity with FluidLoc armored cable and gold-plated ClickLoc connectors.

Product Specifications

• Manufacturer: Bently Nevada (Made in U.S.A)
• Cable Length: 085 = 8.5 meters (27.9 feet)
• Connector & Cable: 13 = Armored FluidLoc with protector
• Approvals: 05 = CSA, ATEX, IECEx
• Cable Weight: 0.618 kg (armored)
• DC Resistance: 1.87 ± 0.28 Ω (core), 0.56 ± 0.11 Ω (jacket)

Technical Details

• Capacitance: 69.9 pF/m (21.3 pF/ft)
• Power Range: -17.5 Vdc to -26 Vdc (12 mA max)
• Pull Strength: 330 N (75 lbf) via CableLoc design
• Humidity Resistance: <3% ASF change in 93% humidity (56 days)
• Field Wiring: Supports up to 305 meters (1,000 feet)

330130-085-13-05 Features: Includes silicone tape for connections, Viton® O-ring seals, and 3-conductor shielded triad compatibility.

Technical Support & Bulk Orders: sales@nex-auto.com

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
