330707-00-24-50-02-00 Bently Nevada | New Proximity Probe

Model Breakdown

• 330707 – 11 mm probe, 1/2-20 UNF thread, with armor
• 00 – No unthreaded length
• 24 – Overall case length: 2.4 in
• 50 – Total cable length: 5.0 m (16.4 ft)
• 02 – Miniature coaxial ClickLoc connector, standard cable
• 00 – No agency approval required

Core Specifications

• Tip material: Polyphenylene sulfide (PPS)
• Case material: AISI 304 stainless steel (SST)
• Cable: 75 Ω triaxial, FEP insulated
• Operating temperature: −52 °C to +177 °C
• Storage temperature: −52 °C to +177 °C
• DC resistance (5 m): 7.2 Ω ± 0.8
• Shipping weight: 0.17 kg
• Minimum bend radius: 25.4 mm (1.0 in)
• Sealing: Viton O-ring for differential pressure

Mechanical Details

• Thread type: 1/2-20 UNF
• Max thread engagement: 0.750 in
• Max torque (case): 45.2 N·m (400 in·lb)
• Recommended torque: 15.2 N·m (133 in·lb)
• Connector torque: Max 0.565 N·m (5 in·lb), finger-tight recommended
• Metric thread options: M16×1.5 (24 mm), M14×1.5 (21 mm)
