330904-08-15-05-12-05 | Bently Nevada New NSv Probe

Description

Bently Nevada 330904-08-15-05-12-05 — 3300 NSv Proximity Probe

Code Breakdown

330904 – Armor-protected NSv probe, M8×1 thread
08 – 80 mm unthreaded length
15 – 150 mm overall case length
05 – 0.5 m cable length
12 – ClickLoc connector + FluidLoc cable
05 – CSA, ATEX, IECEx approvals

Technical Data

Measurement Range: 0.25–1.75 mm (10–70 mils)
Scale Factor: 7.87 V/mm ±20%
Linearity Error: ±0.06 mm max
Bandwidth: DC–10 kHz (up to 305 m wiring)
Operating Temp: –52 °C to +177 °C
Storage Temp: –52 °C to +177 °C

Materials & Construction

Probe Tip: Polyphenylene sulfide (PPS)
Probe Case: AISI 304 stainless steel
Cable: 75 Ω FEP insulated, 0.5 m
Min Bend Radius: 25.4 mm

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
