330908-12-46-70-02-05 – Bently Nevada – Dual 3300 NSv Probe

Description

330908‑12‑46‑70‑02‑05 3300 NSv Proximity Probe Overview

Essential Technical Specifications

Thread Type: 3/8‑24 UNF, without armor

Unthreaded Length: 1.2 in (Suffix: 12)

Overall Case Length: 4.6 in (Suffix: 46)

Probe Cable Length: 7.0 m (Suffix: 70)

Cable Type: 75 Ω FEP-insulated coaxial

Connector: Miniature ClickLoc (Suffix: 02)

Agency Approval: Multiple Approvals (Suffix: 05)

Resistance (RPROBE): 5.9 Ω ± 0.9 at 7.0 m length

Recommended Torque: 11.3 N·m | Max Rated: 33.9 N·m

Maximum Thread Engagement: 0.563 in

Weight: approx. 14 g to 150 g (0.5 to 5.3 oz)

Advanced Functional Details

Operating Temperature Range: –52°C to +177°C (–62°F to +351°F)

Storage Temperature: –52°C to +177°C (–62°F to +351°F)

Shock Resistance: Up to 5000 g peak acceleration

Sealing Method: Viton O-ring, up to 300 psi differential

Electrical Isolation: Dielectric withstand of 2000 VAC

Insulation Resistance: >1 GΩ at 50 VDC

Frequency Response Range: 2 kHz to 20 kHz

Bias Current Requirement: 2.2 mA

Sensing Tip Diameter: 8 mm

Cable Outer Diameter: 2.5 mm

Suffix Code Breakdown

12 = 1.2 in unthreaded portion
46 = 4.6 in case length for extended mounting
70 = 7.0 m probe cable
02 = Miniature ClickLoc coaxial connector
05 = With multiple global agency approvals

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
