330930-040-00-05 Bently Nevada – New Original Cable

Description

330930-040-00-05 Key Technical Highlights

Cable Length: 4.0 meters (13.1 feet)
Material: 75 Ω coaxial, FEP insulated
Operating Temperature: -51°C to +177°C (-60°F to +351°F)
Shipping Weight: 1.5 kg
Agency Approval: 05 = Multiple Approvals
Armor Option: 00 = Without stainless steel armor

Performance Specifications

DC Resistance:
Center Conductor: 0.220 Ω/m (0.067 Ω/ft)
Shield: 0.066 Ω/m (0.020 Ω/ft)

Capacitance: 69.9 pF/m (21.3 pF/ft) typical

Linear Measurement Range:
Total: 1.5 mm (60 mils)
Begins: ~0.25 mm (10 mils) from target
Effective Range: 0.25 to 1.75 mm (10 to 70 mils)
Output Voltage Range: Approximately -1 to -13 Vdc

Recommended Gap Setting: 1.0 mm (40 mils)

Field Wiring Requirements:
Compatible with 0.2 to 1.5 mm² (16 to 24 AWG),
Or 0.25 to 0.75 mm² (18 to 23 AWG) with ferrules
Recommended: Three-conductor shielded triad cable
Maximum Length: 305 meters (1,000 feet) between 3300 XL NSv Proximitor Sensor and monitor

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
