330930-040-02-CN Bently Nevada – New Original Cable

Description

330930-040-02-CN Key Specifications

Length: 4.0 m (13.1 ft)
Armor Option: 02 = Flexible AISI 302 SST without FEP jacket
Approvals: CN = Country‑specific (guide in downloads)
Shipping Weight: 1.5 kg
Shelf Life: 12 months from manufacture

Electrical & Mechanical Details

DC Resistance: Center conductor 0.220 Ω/m (0.067 Ω/ft); Shield 0.066 Ω/m (0.020 Ω/ft)
Capacitance: 69.9 pF/m (21.3 pF/ft)
Dielectric Constant: 2.1 at 1 kHz
Breakdown Voltage: 2 500 Vrms
Shield Coverage: 95 % braid with 0.05 mm foil layer
Braid Density: 32 wires per cm
Tensile Fatigue Cycles: > 10 000 cycles at 100 N load

Field Wiring & Performance

Conductor Range: 0.2–1.5 mm² (16–24 AWG); with ferrules 0.25–0.75 mm² (18–23 AWG)
Maximum Run: 305 m (1 000 ft) to monitor
EMI Attenuation: ≥ 25 dB at 1 MHz with triad cable
Altitude Rating: Certified to 4 000 m above sea level
Minimum Bend Radius: 60 mm (2.4 in)

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
