8 mm ETR Proximity Probes | Bently Nevada 330191-00-70-20-00

Description

Bently Nevada 3300 XL 8mm Proximity Probe: Superior Machinery Monitoring

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8mm ETR Probe
• Full Part Number: 330191-00-70-20-00
• Length Options:
  • Unthreaded: 00 (0.0 in)
  • Case Length: 70 (7 in)
  • Cable Length: 20 (2.0 meters)
• Power: -17.5 to -26 VDC
• Sensitivity: <2 mV/V
• Output Resistance: 50 Ω
• Temperature Range:
  • EPL Ga/Gc: T1 (-55°C to +232°C)
  • EPL Dc: T280°C @ Ta (-55°C to +232°C)
• Cable: 75Ω triaxial FEP (2m length)
• Thread: 3/8-24 UNF

Key Features

• 8mm probe body for maximum durability
• Patented CableLoc and TipLoc technology
• Optional FluidLoc cable prevents oil leaks
• Gold-plated connectors for reliable signal
• Viton® O-ring seal for pressure environments

Installation Guide

Max torque: 0.565 N•m (5 in•lbf). Requires proper grounding per drawing 140979. Use with BN extension cables and Prox systems. Avoid operation above -23.5 VDC to maintain linear range.

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
