991-25-50-03-05 | Bently Nevada – Thrust Transmitter

Description

Bently Nevada 991-25-50-03-05 Thrust Transmitter – Factory-New & Original with 12-Month Warranty. Designed for precision thrust measurement in explosive atmospheres, featuring ±25 mils full-scale range and marine-grade certifications.

Core Specifications:

Measurement Range: 25-0-25 mils (±635 μm) bidirectional monitoring
Cable Length: 5.0m (16.4ft) integral shielded cable
Accuracy: ±0.8% full-scale at 25°C ambient
Housing: IP65-rated aluminum alloy enclosure
Response Time: <2ms signal update rate
Certification Details:
• ATEX Zone 0/2 & CSA Class I Div 2 compliant
• -40°C to 85°C operational temperature range

Configuration Breakdown:
25 = ±25 mils range | 50 = 5m cable | 03 = DIN clip mounting | 05 = Multi-agency approvals

Weight: 0.82kg (1.81lbs) – Compact design for space-constrained installations

For technical support or volume pricing:
Email: sales@nex-auto.com

Download PDF file here:991 Thrust Transmitter Datasheet – 141618
