ABB AC800M | PM866K01 3BSE050198R1 Processor Unit Kit

ABB AC800M PM866K01 Processor Unit Kit – High-Performance Industrial Automation

Model: 3BSE050198R1 | 3BSE076939R1 (PM866AK01)

Key Features

• Processing Power: MPC866 processor @ 133 MHz
• Ultra-Fast Execution: 0.09 ms for 1000 boolean operations
• Memory: 64 MB RAM (51.389 MB available) + 4 MB Flash for firmware
• Real-Time Control: Cycle times down to 1 ms with 32 configurable tasks
• Robust I/O Capacity: Supports up to 96 I/O modules (single CPU) or 84 modules (redundant)

Enhanced Connectivity

• Dual Ethernet Ports: 10 Mbit/s RJ-45 interfaces with MMS/IAC protocols
• High-Speed Modulebus: Scan rate adjustable from 0-100 ms per I/O cluster
• Event Handling: Processes up to 3,000 events in queue with 36-86 events/sec transmission
• 12 CEX Bus Modules: Supports max 2.4A current for expanded communication

Industrial Durability

• Wide Temperature Range: Operates at -40°C to +70°C storage / +5°C to +55°C operational
• Vibration Resistance: 0.5g acceleration (50-150 Hz) & 0.2g (5-500 Hz)
• Certifications: CE, UL, ISA Secure, DNV-GL, RoHS, WEEE, ExnA IIC T4Gc
• Power Efficiency: 5.1W typical consumption (8.6W max) @ 24V DC input

Advanced Specifications

• Redundancy Ready: 10 ms max switch-over time with backup battery (3.6V lithium)
• Precision Clock: ±100 ppm stability (≈1 hr/year deviation)
• Compact Design: 119x186x135 mm, 1.2 kg with IP20 protection
