ABB | AO820 3BSE008546R1 Analog Output Module

3BSE008546R1 Analog Output Module: Precision & Versatility

This 4-channel analog output module delivers exceptional performance with 12-bit resolution and ultra-fast ≤1.5 ms update cycles. Engineered for industrial automation systems requiring reliable signal transmission up to 600 meters.

Core Specifications

• Signal Ranges: ±20mA, 0-20mA, 4-20mA, ±10V, 0-10V, 2-10V
• Accuracy: 0.1% (voltage) | 0.15% max (current)
• Isolation: 1500V channel-to-channel | 500V dielectric withstand
• Response: <0.7 ms rise time with current limiting protection

Enhanced Performance Data

• Temperature Stability: ±0.015%/°C drift (90 ppm/°C max)
• Load Capacity: 550Ω (current) | ≥5kΩ (voltage)
• Power Efficiency: 6W typical consumption | 24V@260mA max
• Environmental: -25°C to +70°C operating | IP20 protection

Physical Configuration

• Compact Design: 45×119×102mm (1.77″×4.7″×4.01″)
• Lightweight: 0.4 lbs (0.18kg) with DIN rail compatibility
• Connector: Removable screw terminal blocks

Technical Support: For configuration guidance or bulk pricing
sales@nex-auto.com

Download PDF file here:S800 IO Environmental Declaration
