ABB | IMDSI14 Digital Slave Input Module

ABB IMDSI14: High-Performance 16-Channel Digital Input Module

Designed for industrial automation, the IMDSI14 delivers 16 optically isolated inputs with exceptional reliability. Engineered to operate in harsh environments, it combines precision with rugged durability.

Core Features

• Ultra-Fast Response: <1ms switching time for real-time control
• Wide Voltage Compatibility: Supports 12-60VDC input range (48VDC nominal)
• Robust Construction: Withstands 1.5kV surge pulses and 1500VAC/min dielectric strength

Technical Specifications

• Input Impedance: 4.7kΩ ±2%
• Power Consumption: 3.8W max @ 48VDC
• Isolation: 3750VRMS input-to-output protection
• Mounting: DIN rail compatible with 120mm x 45mm x 75mm dimensions

Environmental Resilience

• Shock Resistance: 50g peak (11ms duration)
• Vibration Endurance: 5-500Hz @ 1.5g acceleration
• Certifications: UL 508, CE, RoHS compliant

Includes 1-year warranty and IP40 protection rating. Compatible with ABB AC500 PLC systems and third-party controllers via Modbus RTU protocol.

Contact Technical Team: sales@nex-auto.com | Typical lead time: 5-7 business days

Download PDF file here:IMDSI14
