Analog Input Module IC695ALG608 GE Fanuc Emerson

Description

GE Fanuc IC695ALG608 Analog Input Module for RX3i PACSystem

Technical Details

Model: IC695ALG608

Brand: GE Fanuc

Series: PACSystem RX3i

Maker: Emerson Automation (used to be GE)

Type: Analog Input Module, non-isolated

Channels: 8 single-ended or 4 differential

Voltage Input: ±10V, 0-10V, ±5V, 0-5V, 1-5V

Current Input: 0-20mA, 4-20mA, ±20mA

Resolution: 24-bit

Output Format: Float 32-bit or Int 16-bit

Filters: 8, 12, 16, 40, 200, 500 Hz

Power Use: 330mA at 5V, 600mA at 3.3V

Work Temp: 0 to 60 °C

Storage Temp: -40 to 85 °C

Humidity: 5% to 95%, no condensation

Protection: Max ±60 VDC overvoltage

Input Resistance: >100kΩ for voltage, 249Ω ±1% for current
