Bently Nevada 11 mm Proximity Probes | 330710-000-060-10-02-00

Description

Bently Nevada M16 Vibration Probe with Short Cable

Product Overview

New Bently Nevada vibration sensor. Part 330710-000-060-10-02-00. Features M16 threading and 1m cable. Made in USA. 1-year warranty.

Key Specifications

• Brand: Bently Nevada
• Model: 3300 XL 11mm
• Part Code Details:
  • 330710: Armored M16 probe
  • 000: No unthreaded section
  • 060: 60mm case length
  • 10: Short 1m cable
  • 02: ClickLoc connector
  • 00: No approvals needed
• Temp Range: -52°C to 177°C
• Thread Size: M16 x 1.5

Technical Features

• Output: 5.9Ω resistance
• Cable Length: 1 meter
• Body Material: Stainless steel
• Tip Material: Special PPS plastic
• Min Bend Radius: 25.4mm

Installation Guide

• Max case force: 63.3 N•m
• Best case force: 21.1 N•m
• Connector force: Finger tight only
• Thread depth: Max 24mm
• Note: Keep above -34°C

Compatibility

• Min Target Size: 30.5mm diameter
• Min Shaft Size: 152mm diameter
• Works with 3300 XL systems

Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
