Bently Nevada – 3300 NSv Extension Cable – 330930-060-01-00

Description

Manufacturer: Bently Nevada

Model: 330930-060-01-00

Type: 3300 NSv Extension Cable

Origin: Made in U.S.A

Length: 6.0 meters (19.7 feet)

Cable: With stainless steel armor and FEP jacket

Material: 75 Ω coaxial, FEP insulated

Operating Temp: -51°C to +177°C (-60°F to +351°F)

Weight: 1.5 Kg

Important: Extension cable length plus probe length must equal total sensor length.

Electrical Specs:

• Center conductor resistance: 0.220 Ω/m (0.067 Ω/ft)
• Shield resistance: 0.066 Ω/m (0.020 Ω/ft)
• Capacitance: 69.9 pF/m (21.3 pF/ft)

Wiring: Use shielded triad cable, 0.2–1.5 mm² (16–24 AWG), max length 305 m (1,000 ft).

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
