Bently Nevada – 3300 NSv Probe 330901-00-10-05-01-00

Description

330901-00-10-05-01-00 NSv Proximity Probe

The 330901-00-10-05-01-00 probe is made in the USA. It has a stainless steel case. The tip is PPS. It works from –52°C to +177°C. It holds full accuracy for one year.

Model Suffix

• 330901: NSv series probe
• -00: No unthreaded section, 0 in
• -10: Case length 1.0 in
• -05: Cable length 0.5 m (20 in)
• -01: ClickLoc connector with protector
• -00: No agency approval

Key Specs

• Tip diameter: 8 mm
• Cable outer diameter: 3.8 mm
• Cable: 75 Ω FEP coax, lengths 0.5, 1, 5, 7 m
• DC resistance (0.5 m): 4.0 ± 0.5 Ω
• Connector torque: max 7.3 N·m, rec. 5.1 N·m
• Max thread engagement: 0.375 in
• Detect range: 0.5 mm
• Resolution: 0.005 mm
• Shock rating: 500 g half‑sine
• Dielectric strength: 2000 VAC
• Min bend radius: 25 mm

Performance

The Viton O‑ring seals pressure. It reads events up to 11 kHz. Accuracy stays within ±1% full scale. It weighs about 18 g.
