Bently Nevada – 330102-10-45-10-02-00 Probes

Description

Bently Nevada 330102-10-45-10-02-00 | 8mm Proximity Probe

📏 Key Tech Details

• Model: 330102-10-45-10-02-00 (Suffix decoded: 1″ unthreaded, 4.5″ case, 1m cable, ClickLoc-02 connector)
• Range: 0.25–2.3mm | Output: -1 to -17 Vdc
• Accuracy: ±0.50Ω @1m | Thread: 3/8-24 UNF
• Temp Survival: -52°C to +260°C (cable) | Avoid <-34°C

🔧 Setup Made Simple

• ▶️ Mounting: Max 0.563″ thread engagement | Use shielded triad cable
• ▶️ Gap Calibration: Set to -9 Vdc (1.27mm) for best vibration sensitivity
• ▶️ Wiring: Up to 305m field wiring | 16-24 AWG recommended

🛡️ Certifications & Safety

• ✅ AEx/Ex ia IIC T5-T1 Ga (Zone 0)
• ✅ AEx/Ex ec IIC T5-T1 Gc (Zone 2)
• ⚠️ Note: Pressure seal uses Viton® O-ring – contact factory for custom testing

📦 Unbox Your Solution

• Included: Probe unit, ClickLoc-02 connector, O-ring seal, user manual
• 1-Year Hassle-Free Warranty – defects coverage

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
