Bently Nevada 330174-00-02-10-02-CN – Armored Proximity Probes

Description

Bently Nevada 330174-00-02-10-02-CN – 5mm Proximity Probe (M8 x 1 Thread, 20 mm Case, 1.0 m Cable)

Key Features

Thread Type: M8 x 1

Overall Case Length: 20 mm

Total Cable Length: 1.0 m (3.3 ft)

Connector: Miniature coaxial ClickLoc, standard cable

Agency Approval: CN – Country Specific

Country of Origin: Made in U.S.A. (Certificate of Origin available)

Electrical Specifications

• Operating Voltage: –17.5 Vdc to –26 Vdc
• Current Consumption: 12 mA max
• Output Resistance: 50 Ω
• Supply Sensitivity: <2 mV change in output per volt input change
• DC Resistance (1.0 m): 7.59 ± 0.50 Ω

Mechanical & Environmental

• Probe Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 304 stainless steel
• Probe Cable: 75 Ω triaxial, FEP insulated
• Weight: 0.323 kg
• Tensile Strength: 222 N (50 lbf)
• Recommended Case Torque: 5.1 N·m (45 in·lb), Max 7.3 N·m (65 in·lb)
• Connector Torque: Max 0.565 N·m (0.42 ft·lb)
• Minimum Cable Bend Radius: 25.4 mm (1.0 in)
• Temperature Range: –35°C to +177°C (–31°F to +351°F)

Download PDF file here:3300 5 mm Transducer System Datasheet – 172036
