Bently Nevada 330425-01-05 | Accelerometer Acceleration Tranducer

Manufacturer: Bently Nevada

Product No.: 330425-01-05

Mounting Thread Option: 0 1 ¼-28 UNF integral stud

Agency Approval Option: Multiple approvals (CSA, ATEX, IECEx)

Key Specifications

Sensitivity: 10.2 mV/m/s² (100 mV/g) ±5%

Acceleration Range: 490 m/s² (50 g) peak overall within the 10 Hz to 15 kHz frequency span.

Note: Vibration at frequencies above 15 kHz may reduce this range significantly.

Amplitude Linearity: ±1% to 490 m/s² (50 g) peak.

Broadband Noise Floor (10 Hz to 15 kHz): 0.039 m/s² (0.004 g) rms.

Frequency Response: 10 Hz to 15 kHz (600 cpm to 900,000 cpm) ±3dB; 30 Hz to 10 kHz (1800 cpm to 600,000 cpm) ±10%

Performance Characteristics

Temperature Sensitivity: -11% to +3% typical over the operating temperature range.

Transverse Sensitivity: Less than 5% of axial.

Mounted Resonant Frequency: Greater than 30 kHz.

Amplitude of Resonant Peak: 20 dB maximum.

Base Strain Sensitivity

For serial numbers preceded by the letter “G”: 49 mm/s²/mstrain (0.005 g/mstrain)

For serial numbers NOT preceded by the letter “G” (shipped prior to April 2004):
980 mm/s²/mstrain (0.100 g/mstrain) without Mounting Base;,
4.9 mm/s²/mstrain (0.0005 g/mstrain) with Mounting Base supplied with the accelerometer.

Bently Nevada recommends installing with the Mounting Base to minimize base strain sensitivity for units NOT preceded by “G”.

Power and Environmental Specifications

Maximum Cable Length: 305 metres (1000 ft) with no degradation of signal.

Power Requirements: Input Voltage -24 ± 0.5 Vdc; Bias Current 2 mA nominal; Output Bias Voltage: -8.5 ± 0.5 Vdc; Grounding: Case isolated.

Operating and Storage Temperature: -55°C to +121°C (-67°F to +250°F)

Shock Survivability: 49,050 m/s² (5000 g) peak, maximum.

Relative Humidity: 100% condensing, nonsubmerged. Case is hermetically sealed.

Magnetic Field Susceptibility: < 2.21 mm/s²/gauss (225 mg/gauss) [50 gauss, 50-60Hz].

IP Rating: Equivalent to an IP 68 (Dust tight and watertight).

Physical Specifications

Weight (no cable): 99 g (3.5 oz), typical.

Diameter: 23 mm (0.93 in).

Height: 59 mm (2.3 in), including mounting stud.

Connector: 3-pin MIL-C-5015 Receptacle, 316L stainless steel.

Mounting Torque: 4.1 N·m (3.0 ft·lb).

Case Material: 316L stainless steel.

Mounting Angle: Any orientation.
