Bently Nevada 330903-00-03-10-01-00 Proximity Probes

Description

Bently Nevada 330903-00-03-10-01-00 3300 NSv Proximity Probe

What This Probe Does

A tough industrial sensor made by Bently Nevada. It works well in harsh places and resists chemicals better than older models. Great for process compressors and rotating machines.

Model Code Explained

330903 (main model) + -00 (00mm unthreaded length) + -03 (30mm case length) + -10 (1.0m total length) + -01 (Mini ClickLoc connector with protector, standard cable) + -00 (no extra approvals needed).

Key Tech Specs

Measure range: 0.25mm to 1.75mm (10-70 mils)
Best gap: 1.0mm (40 mils)
Scale rate: 7.87V/mm (200mV/mil), ±12.5/-20%
Freq range: 0-10kHz (with up to 305m wiring)
Temp work: -52°C to +177°C (-62°F to +351°F)
Resistance: 4.2±0.5Ω (1.0m length)

Install Help

Twist tight: Use fingers. Max 0.56N•m (5in•lb).
Bend min: 25.4mm (1.0in) (with/without armor).
Wire type: 3-conductor shielded (16-24 AWG). Max 305m (1,000ft) to monitor.

Works With Old Models

Fits Bently Nevada’s 3300 RAM probes. Swap them without extra setup.

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
