Bently Nevada – 330904-00-10-70-12-05 – Proximity Probe

Description

330904-00-10-70-12-05 Probe Overview

Technical Highlights

• Shock Tolerance: 50 g half-sine, 11 ms
• Vibration Endurance: 12 g RMS, 10–200 Hz
• Response Time: < 0.1 ms to 90%
• Tip Hardness: PPS material at Shore D 75
• Output Impedance: 75 Ω (cable characteristic)
• Insulation Resistance: ≥1×10⁹ Ω at 500 Vdc
• Dielectric Strength: 1 000 V for 60 s
• Cable Diameter: 5.3 mm outer

Ordering & Suffix Breakdown

Base Model: 330904
-00 = 0 mm unthreaded tip, -10 = 100 mm case, -70 = 7.0 m cable, -12 = ClickLoc connector, -05 = ATEX/IECEx/CE approvals
Operating Temp: –52 °C to +177 °C
Warranty: 1 year

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
