Bently Nevada 330909-00-20-10-02-00 | Armored Probes

Description

330909-00-20-10-02-00 3300 NSv Proximity Probe Highlights

The 330909-00-20-10-02-00 model combines rugged AISI 304 stainless steel housing with a PPS tip for precise vibration monitoring up to 5 kHz and shock resistance of 5000 g.

Core Specifications

• Threaded case: 3/8‑24 UNF, recommended torque 11.3 N·m, max 33.9 N·m
• Case length: 2.0 in; unthreaded length: 0.0 in
• Cable length: 1.0 m (39 in); minimum bend radius 50 mm
• Connector: Miniature coaxial ClickLoc with protector
• Bandwidth: DC to 10 kHz; sensitivity: 100 mV/mil
• Linearity error: ±0.5%; dynamic range ±2 mm
• Operating/storage: –52 °C to +177 °C; shelf life: 12 months

Suffix Code Breakdown

• 00 = Unthreaded length 0.0 in
• 20 = Case length 2.0 in
• 10 = Cable length 1.0 m
• 02 = ClickLoc connector, standard cable
• 00 = No agency approvals required

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
