Bently Nevada – 330910-00-08-70-01-05 – New Armored Probes

Description

Bently Nevada 330910-00-08-70-01-05 3300 NSv Proximity Probe

Model Code Details

• 330905 – NSv Probe with M10X1 thread, stainless steel armor
• -00 – 0 mm Unthreaded Length
• -08 – 80 mm Case Length
• -70 – 7.0 meters Total Cable Length
• -01 – ClickLoc connector with protector
• -05 – Multiple Safety Approvals

Key Technical Data

• Measurement Range: Up to 2 mm
• Accuracy: ±0.07 mm typical
• Output: Eddy current voltage signal
• Resistance: 5.9 ± 0.9 ohms (for 7.0 m length)
• Tip Material: PPS plastic
• Case Material: 304 stainless steel
• Cable: 75 Ω coaxial, FEP insulated
• Minimum Bend Radius: 25.4 mm
• Thread Size: M10X1, max 15 mm thread engagement
• Case Torque: 11.3 N·m recommended
• Working Temperature: -52°C to +177°C
• Storage Temperature: -52°C to +177°C

Where to Use

• Gas Turbines: Monitors shaft movement
• Compressors: Finds misalignment or vibration early
• Pumps and Gearboxes: Prevents damage from faults
• Machines with tight space: Slim design fits easily

Problems Solved

• Small installation space? The probe fits well
• Need early fault alerts? It gives fast, accurate data
• Harsh environment? It resists heat and chemicals
• Protect your machine? Detects shaft issues early

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
