Bently Nevada – 330910-07-23-70-02-00 – New Armored Probes

Description

Bently Nevada 330910-07-23-70-02-00 3300 NSv Proximity Probe

Main Features

• Model: 330905 with M10X1 thread and metal armor
• Unthreaded Length: 70 mm
• Case Length: 230 mm
• Cable Length: 7.0 meters (23 feet)
• Connector: Mini ClickLoc, standard cable
• Resistance: 5.9 ± 0.9 Ohms

Technical Details

• Signal Type: Non-contact, analog
• Tip Material: PPS plastic
• Case Material: Stainless steel
• Cable Type: 75 Ω coaxial, FEP insulated
• Available Cable Sizes: 0.5 m, 1 m, 5 m, 7 m
• Bend Radius: Minimum 25.4 mm
• Weight: 14 to 150 grams

Temperature Range

• Working Temp: -52°C to +177°C
• Storage Temp: -52°C to +177°C
• Note: Below -34°C for long time may damage the seal

Temperature Ratings

• T1: -55°C to +232°C
• T2: -55°C to +177°C
• T3: -55°C to +120°C
• T4: -55°C to +80°C
• T5: -55°C to +40°C

Installation Info

• Thread: M10X1
• Max Thread Depth: 15 mm
• Torque Recommended: Finger tight
• Max Torque: 0.56 N·m

Model Breakdown

• 330910 – NSv Probe Series
• -07 – 70 mm unthreaded length
• -23 – 230 mm case length
• -70 – 7.0 meter cable
• -02 – Mini ClickLoc, standard cable
• -00 – No approval needed

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
