Description

Bently Nevada 3300 XL 8mm Vibration Probe

Model: 330103-02-07-05-02-05

Key Features

  • ✓ M10×1 threaded design
  • ✓ 70mm compact case
  • ✓ 20mm unthreaded length
  • ✓ 0.5m cable included
  • ✓ ATEX/CSA/IECEx certified
  • ✓ Stainless steel construction

Technical Specifications

Measurement Range0.25-2.3mm (10-90 mils)
Output Signal-1 to -17 Vdc
Temperature Range-52°C to +177°C
Thread SizeM10×1 (15mm max)

Model Number Explained

  • 330103 – 8mm probe without armor
  • 02 – 20mm unthreaded length
  • 07 – 70mm case length
  • 05 – 0.5m cable
  • 02 – ClickLoc connector
  • 05 – CSA/ATEX/IECEx approvals

Installation Guide

  1. Mount using M10×1 thread (max 15mm depth)
  2. Set gap to 1.27mm (50 mils)
  3. Connect using shielded cable (0.2-1.5mm²)

Safety Certifications

ATEX | CSA | IECEx

Common Applications

  • Industrial turbines
  • Compressors
  • Pump systems
  • Electric motors

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet

Additional information

Weight0.323 kg
Dimensions23 × 23 × 4 cm
