Bently Nevada 991-06-70-02-05 – 991 Thrust Transmitter

Description

Bently Nevada 991-06-70-02-05 Probe Vibration Transmitter

This transmitter monitors axial displacement. It uses strong design and standard outputs to protect machinery. Good for centrifugal compressors, pumps, and motors, it gives key data for machine checks.

Model & Features

Model parts
991: Thrust Transmitter Series
-06: 0.6-0-0.6 mm range
-70: 7.0 meters (23.0 feet) length
-02: Bulkhead screws for mounting
-05: Certified (CSA Division 2, ATEX Zone 0/2, ABS maritime)

Electrical specs
Output: 4-20 mA (2-wire)
Power: +12 to +35 Vdc
Accuracy: ±1.5% of full scale (normal, tested with 250 Ω load)
Max resistance: 1,000 Ω (at 35 Vdc)
Current limit: 23 mA (normal)

Size & Environment
Mount: DIN rail
Weight: 0.43 kg (0.9 lbm)
Work temp: -35°C to +85°C (-31°F to +185°F)
Store temp: -51°C to +100°C (-60°F to +212°F)
Humidity: Handles 100% humidity with condensation

Safety & Warranty
Fault signal: <3.6 mA within 100 µs
Back to work: Restores in 0.1 seconds after fault
Certificates: CSA Division 2, ATEX Zone 0/2, ABS maritime
Warranty: 1 year

Download PDF file here:991 Thrust Transmitter Datasheet – 141618
