Bently Nevada 991-06-70-03-05 Thrust Transmitter

Description

Bently Nevada 991-06-70-03-05 Probe Vibration Transmitter

This transmitter helps check axial movement in machines. It uses strong design and standard 4-20 mA output to keep machinery safe. Good for pumps, compressors, and motors, it gives clear data for machine health checks.

Model Details

Model parts explained
991: Thrust Transmitter Series
-06: 0.6-0-0.6 mm working range
-70: 7.0 meters (23.0 feet) total length (probe + cable)
-03: DIN clips and screws for easy mounting
-05: Approved for safety (CSA Division 2, ATEX Zone 0/2, ABS maritime)

Electrical Specs

Output: 4-20 mA (2-wire setup)
Power needed: +12 to +35 Vdc
Accuracy: ±1.5% of full range (normal, tested with 250 Ω load)
Max resistance: 1,000 Ω (at 35 Vdc)
Current limit: 23 mA (normal)

Size & Environment

Mount: Fits DIN rail with clips and screws
Weight: 0.43 kg (0.9 lbs)
Work temp: -35°C to +85°C (-31°F to +185°F)
Store temp: -51°C to +100°C (-60°F to +212°F)
Humidity: Handles up to 95% humidity (no condensation)

Download PDF file here:991 Thrust Transmitter Datasheet – 141618
