Bently Nevada Armored Proximity Probes | 330909-00-20-70-01-00

330909‑00‑20‑70‑01‑00 NSv Proximity Probe Overview

Suffix Code Breakdown

• ‑00 = 0.0 in unthreaded length
• ‑20 = 2.0 in overall case length
• ‑70 = 7.0 m cable length (23.0 ft)
• ‑01 = ClickLoc connector with protector, standard cable
• ‑00 = No agency approval required

Technical Specifications

• Case material: AISI 304 stainless steel
• Tip material: PPS (Polyphenylene sulfide)
• Cable type: 75 Ω coaxial with FEP insulation
• Resistance at 7.0 m: 5.9 Ω ± 0.9 Ω
• Max connector torque: 33.9 N·m
• Thread torque (first 3 threads): 22.6 N·m
• Thread engagement: 0.563 in max
• Weight: 14–150 g (0.5–5.3 oz)
• Operating temperature: −52 °C to +177 °C
• Storage temperature: −52 °C to +177 °C
• Shelf life: 1 year
• Sealing: Viton O-ring for pressure differential isolation
• Ingress protection: IP66 rated (new)
• Frequency range: 0 to 10 kHz (new)
• Dielectric strength: 1500 V RMS (60 Hz) (new)
• Acceleration limit: 20 g peak, 10–2000 Hz (new)
