Bently Nevada Armored Proximity Probes | 330909-00-60-70-01-05

Description

Product Model: 330909-00-60-70-01-05

Product Type: 3300 NSv Proximity Probe

Model Details:
00 – No unthreaded length
60 – 6.0-inch case length
70 – 7.0-meter total cable (23 feet)
01 – Mini ClickLoc connector with cover
05 – Multiple safety approvals

Materials:
Case: AISI304 stainless steel
Tip: Polyphenylene sulfide (PPS)

Cable:
75-ohm coaxial, with FEP insulation
This version has a 7.0 m cable

Resistance:
For 7.0 m length: 5.9 ± 0.9 ohms

Thread Info:
Thread type: 3/8-24 UNF
Max thread depth: 0.563 in
Recommended torque: 11.3 N·m (100 in·lb)
Max torque: 33.9 N·m (300 in·lb)

Temperature Range:
Use range: -52°C to +177°C (-62°F to +351°F)
Storage: -52°C to +177°C
Avoid long use below -34°C (-30°F) to protect the seal.

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
