Bently Nevada – Thrust Transmitter ‎990-05-50-01-00

Description

Model Code & Key Details

Brand: Bently Nevada
Type: 990 Vibration Transmitter
Model Breakdown:990-05-50-01-00

990: Base model series
05: Measures 0-5 mils pp (0-125 μm pp)
50: Works with 0-5.0 meters (16.4 feet) systems
01: Uses 35 mm DIN rail clips for mounting
00: No special approvals needed

Main Features

Input: Works with 1 3300 NSv Proximity Probe + extension cable.
Power: Needs +12 to +35 Vdc.
Output: 4-20 mAdc (2-wire setup).
Accuracy: ±1.5% of full range (adds to Prox Out scale).
Max Resistance: 1,000 Ω (at 35 Vdc).
Current Limit: 23 mA (normal).
Probe Gap: 0.5-1.75 mm (20-55 mils) for full use.
Weight: 0.43 kg (0.9 lbs).
Frequency Range: 5 Hz to 6,000 Hz (-3 dB).
Min Target Size: 9.5 mm (0.375 in) wide.

Download PDF file here:990 Vibration Transmitter Datasheet
