DC Voltage Input Module GE Fanuc Emerson IC694MDL660

Description

IC694MDL660 32-Point DC Input Module

The IC694MDL 660 is a 24 VDC input module with 32 channels. It is part of the RX3i PACSystem series from GE Fanuc, now under Emerson Automation. It works with both positive and negative logic.

Model and Suffix

Model: IC694MDL
Suffix: 660

Key Specifications

Total Inputs: 32 points

Groups: 4 groups, 8 channels each

Voltage Range: 0–30 VDC (Nominal: 24 VDC)

Input Current: 7 mA per point

On-State Voltage: 11.5–30 VDC

Off-State Voltage: 0–5 VDC

On-State Current: 3.2 mA

Off-State Current: 1.1 mA

Isolation: 250 VAC continuous; 1500 VAC for 1 minute

Power Draw: 195 mA @ 5 VDC, 224 mA @ 24 VDC

Max Inrush Current: 4.78 A for 10 ms

Operating Temp: 0–60 °C

Warranty: 1 year
