IC697MDL640 | Series 90-70 PLC Module

Description

IC697MDL640 Input Module Overview

The IC697MDL640 by GE Fanuc is a discrete input module with 16 input points in 4 isolated groups of 4 points each. It works with 125 V DC and supports both positive and negative logic.

Main Specifications

Rated Voltage: 125 V DC
Input Current: 5 mA at rated voltage
Current Required: 0.3 A
Input Voltage Range: –35 to 145 V DC
Logic Type: Positive & Negative
Input Filter: 1 ms or 10 ms selectable
Inputs: 16 points (4×4)

Features

This module meets IEC input standards and can work with proximity switches. One input can be set as an interrupt input when used with GE IC697 PLCs. LEDs show on/off states for each point on the PLC side, making monitoring easy.

Shelf life: 1 year
