IC697MDL651 Series 90-70 PLC Module

Description

Overview

The GE Fanuc IC697MDL651 is a Series 90‑70 discrete input module featuring 32 independent TTL‑compatible channels. Ideal for high‑level industrial control systems.

Key Specifications

• Rated Voltage: 5 Volts DC (–3 to 7 V DC range)
• Input Channels: 32 per module
• Current Consumption: 0.53 A @ 5 V DC bus
• On‑State Current: Typ. 1.7 mA (–3 to 0.5 V input)
• Off‑State Current: Max 1.1 mA (2 to 7 V input)
• Isolation Voltage: 1500 V
• Max Cable Length: 30 m (98.4 ft)
• Filter Options: 1 ms or 10 ms
• Input Impedance: 5.9 kΩ ±5%

Environmental & Mechanical

• Operating Temp.: –20 °C to +70 °C
• Storage Temp.: –40 °C to +85 °C
• Shelf Life: One year
• Module Weight: Approx. 0.15 kg
• Compliance: VME Standard (C.1)
