New 3300 NSv Probe Bently Nevada | 330903-00-03-10-01-05

Description

Bently Nevada 3300 NSv Proximity Probes – Simple & Reliable Industrial Sensors

Product Basics

Brand: Bently Nevada
Model: 3300 NSv Proximity Probes
Part Number: 330903-00-03-10-01-05 (What each part means:

330903: Base model (M8X1 thread, no armor)
-00: No extra unthreaded length
-03: Case length 30mm
-10: Total probe length 1.0m (39in)
-01: Small coaxial connector with standard cable
-05: Passes multiple safety tests)

Key Features

Measure Range: Checks from 0.25mm to 1.75mm (10-70 mils). Best gap: 1.0mm (40 mils).
Accuracy: Scale factor 7.87V/mm (±12.5%/-20%). Error less than ±0.06mm.
Signal Output: Sends -1 to -13Vdc.
Frequency: Works up to 10kHz (even with 305m wiring).
Temp Range: Runs/stores from -52°C to +177°C.
Cable: 75Ω coaxial, FEP-insulated (lengths: 0.5/1/5/7m).

Works with Old Models

Fits Bently Nevada’s older 3300 RAM probes. Better at fighting chemicals than RAM. Better side-view than 3000-series 190 probes at same gap.

How to Install

Tighten: By hand. Max torque: 0.56N•m (5in•lb).
Bend: Min 25.4mm (1in) (with/without armor).
Wiring: Use 3-conductor shielded cable (0.2-1.5mm²). Max length: 305m (1,000ft).

Certificates & Warranty

Tests Passed: Multiple (from part -05).
Packaging: Brand new, in factory box.
Warranty: 1 year from delivery.

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
