New 3300 NSv Probe Bently Nevada | 330903-00-04-10-11-05

Description

3300 NSv Probe – M8×1 Thread, 1 m FluidLoc Cable

Overview

Top‑grade Bently Nevada sensor for demanding compressor tasks. PPS tip and 304 SST casing resist corrosion and wear.

Specs at a Glance

• Brand: Bently Nevada
• Model: 330903-00-04-10-11-05
• Suffix:
  00 mm unthreaded,
  04 mm case,
  10 = 1 m cable,
  11 = FluidLoc ClickLoc,
  05 = multi‑approval
• Range: 0.25–1.75 mm
• Accuracy: < ±2.3 mils DSL
• Output: 7.87 V/mm
• Freq: 0–10 kHz (≤ 305 m cable)
• Temp: –52 °C to +177 °C

Quick Setup

Screw into M8×1 port until hand‑tight. Torque max 0.56 N·m. Maintain ≥ 25 mm bend radius. Use shielded triad cable.

Compatibility

Works with 3300 RAM and 3000‑190 series. Accepts any 75 Ω FEP cable up to 305 m.

Certs & Seals

Global approvals. Viton O‑ring seal for pressure. Optional custom seal testing.

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
