NSv Proximity Probe – Bently Nevada – 330905-00-20-10-02-05

Description

Bently Nevada 330905-00-20-10-02-05 Proximity Sensor

Advanced Vibration Monitoring

New 3300 NSv Proximity Probe for industrial machinery protection. Features enhanced chemical resistance and superior side-view performance. Direct replacement for 3300 RAM probes with improved capabilities.

Complete Model Specifications

Brand: Bently Nevada

Base Model: 330905 (M10X1 thread, no armor)

Suffix -00-: 00 mm unthreaded length

Suffix -20-: 200 mm overall case

Suffix -10-: 1.0 m cable length

Suffix -02-: Miniature ClickLoc connector

Suffix -05: Multiple agency approvals

Key Performance Data

Measurement Range: 1.5 mm (60 mils)

Accuracy: ±0.06 mm (±2.3 mils)

Output Signal: -1 to -13 Vdc

Temp Range: -52°C to +177°C

Response: 0-10 kHz (±3dB)

Installation Guide

Set 1.0 mm gap to target surface. Apply 7.5 N•m torque maximum. Maintain minimum 25.4 mm bend radius. Use flat targets >13 mm diameter.

Seamless Compatibility

Mechanically and electrically matches 3300 RAM probe systems. Works with standard 75Ω coaxial cables up to 305 meters.

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
