Proximity Probe Bently Nevada | 330903-00-02-10-01-05

Description

3300 NSv Proximity Probe – M8X1 Thread, 1 m Cable

Description

Reliable Bently Nevada sensor with high chemical resistance. Delivers stable readings in harsh compressor environments. Compact PPS tip and stainless‑steel case ensure long life.

Technical Data

• Brand: Bently Nevada
• Model: 330903-00-02-10-01-05
• Suffix details:
  00 mm unthreaded,
  02 mm case,
  10 = 1.0 m cable,
  01 = ClickLoc connector,
  05 = multi‑approval
• Range: 0.25–1.75 mm (10–70 mils)
• Accuracy: ±2.3 mils DSL
• Output: 7.87 V/mm (200 mV/mil)
• Frequency: 0–10 kHz (up to 305 m wiring)
• Temp: –52 °C to +177 °C

Installation Guide

Thread probe into M8×1 port until finger‑tight. Torque max 0.56 N·m. Use shielded triad cable. Keep bend radius ≥ 25 mm.

Compatibility

Fits 3300 RAM systems and 3000‑series 190 targets. Works with any 75 Ω FEP‑insulated cable up to 305 m.

Certifications

Multiple approvals for global use. Viton O‑ring seal rated for differential pressure. Contact for custom tests.

Packing List

• 3300 NSv Probe (1 m cable)
• Connector protector
• Installation leaflet

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
