Proximity Probe – Bently Nevada 330904-00-15-70-12-05

Description

330904-00-15-70-12-05 Probe Overview

Enhanced Physical Attributes

• Probe Tip Diameter: 4.8 mm
• Cable Attenuation: 0.005 dB/m at 1 kHz
• Maximum Shock Tolerance: 50 g (11 ms half-sine)
• Maximum Vibration Tolerance: 10 g up to 200 Hz
• O-Ring Compression: 0.5 mm at 2 bar
• Bend Life: >250 000 cycles at 25 mm radius

Advanced Electrical & Environmental

• Dielectric Strength: 1 000 V for 1 minute
• EMI Immunity: ≥25 V/m (80–1 000 MHz)
• Cable Capacitance: 69.9 pF/m
• Max Differential Pressure Seal: 5 bar
• Output Current Limit: 12 mA
• Linear Range: 0.25–1.75 mm (10–70 mils)
• Scale Factor: 7.87 V/mm ±20%

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
