Reverse Mount Probe Bently Nevada 330907-05-30-10-12-05

Description

Bently Nevada 3300 NSv Reverse Mount Probe – Precision Vibration Monitoring

Product Overview

Brand: Bently Nevada
Model: 330907-05-30-10-12-05
A reverse-mount vibration probe with enhanced chemical resistance for harsh environments. Features gold-plated ClickLoc connectors and PPS probe tip for reliable performance in process compressors.

Key Features

• ✓ M10X1 thread & 1.0m armored cable
• ✓ 1.5mm linear range (-1 to -13Vdc output)
• ✓ Withstands -62°F to +351°F
• ✓ ATEX/IECEx certified (Approval Option 05)

Technical Specifications

Core Parameters

• Range: 0.25-1.75mm (10-70 mils)
• Accuracy: ±0.5Ω resistance variance
• Output: -1 to -13Vdc linear signal
• Thread: M10x1 (15mm engagement)

Model Suffix Details

• -05: Multi-agency certifications
• -30: M10x1 threading
• -10: 1.0m cable length
• -12: ClickLoc/FluidLoc connector

Installation Guide

• Max torque: 7.5 N•m (66 in•lb)
• Use 3-conductor shielded cable (max 305m)
• Optimal gap: 1.0mm (40 mils)

Certifications & Compliance

Approved for use in hazardous areas with multiple international certifications (Option 05). Includes Certificate of Origin upon request.

Real-World Applications

• Gas compressor vibration monitoring
• Steam turbine protection systems
• Offshore platform machinery

Package Contents

• 3300 NSv probe unit
• Installation manual
• COO document (optional)
• 1-year warranty

Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
