Schneider | TSXISPY101 Modicon ISP Plus Weighing Module

Description

TSXISPY101 ISP Plus Weighing Module delivers 50 measurements/second with ultra-precise 20-bit resolution, making it ideal for industrial automation. Integrated into the Modicon Premium Automation Platform, this module ensures seamless compatibility and high-speed data acquisition.

Key Specifications

• Precision Metrics: 1μV voltage division & 1048576-point resolution
• Sensor Support: Accommodates 1-8 load cells (350Ω) with 300m cable range
• Output Power: 24V DC discrete output at 500mA, reacting in 1ms
• Communication: RS485 serial link at 9.6 kbit/s, effective within 30m
• Environmental Resilience: Operates at 0-60℃ & withstands 10-95% humidity
• Power Efficiency: Consumes 145mA @24V & 150mA @5V DC

Enhanced Features

• Mechanical Stability: Vibration resistance up to 5g @ 10-150Hz
• Longevity: Designed for 100,000+ hour MTBF (Mean Time Between Failures)
• Certifications: Complies with CE & IP40 protection rating

With a compact 0.42kg design and standard module format, this solution optimizes space in control cabinets. Inquiries: sales@nex-auto.com
